Generated with Style2AI - this is actual product output, not a stock photo.
Transform a flat CAD elevation into a photorealistic rendered facade in a secure, NDA-compliant workspace. Your drawings and IP remain yours and are never used for training. Communicate material and finish intent to clients instantly.
Technical specifications
| Supported inputs | .dwg, .dxf, PNG/JPG of the elevation |
|---|---|
| Output type | Photorealistic rendered elevation |
| Output resolution | Up to 4K (Pro) / 8K (Studio) |
| Export formats | PDF, Excel takeoff (.xlsx), DXF, PNG |
| Turnaround | Seconds-minutes (vs days traditionally) |
| Data privacy | NDA-compliant - your IP stays yours - no model training |
How it works
- Export your CAD elevation as an image or DXF.
- Upload to the secure workspace and select the elevation render workflow.
- Prompt the cladding, glazing, and finish materials.
- Generate variants and pick the strongest option.
- Export at up to 4K/8K as PNG, with supporting DXF.
One workspace, the whole deliverable set
The render is step one. The same secure project also produces the documentation and presentation material around it:
Renders & visualization
Photorealistic stills up to 4K/8K, style and ambiance control, camera angles, upscaling, and inpaint editing. Learn more →
360° panoramas & video
Immersive 360° panoramas clients can look around, plus AI walkthrough video from stills or text. Learn more →
Elevations & CAD export
Styled elevations and true vector exports - DXF for AutoCAD, SVG, and PDF - from any render or photo. Learn more →
Schedules & specifications
18 professional list types: FF&E and finish schedules, CSI MasterFormat specs, material takeoffs, shopping lists, and cost estimates - exported to Excel, PDF, or Word. Learn more →
Mood & material boards
Presentation-ready mood boards, labeled material boards, and FF&E palettes in your project's visual language. Learn more →
Design canvas & diagrams
An infinite canvas with sheets, annotation, and AI tools, plus concept diagrams extracted from your imagery. Learn more →
Try this workflow in your secure, NDA-compliant workspace.
Your project IP stays yours. No model training on your data.
Open Secure WorkspaceFrequently asked questions
Does the elevation stay dimensionally faithful?
The workflow preserves the elevation composition while applying realistic materials and shadows.
Is my CAD data private?
Yes - NDA-compliant, never used for training, and your IP stays yours.
